FFG — Force Feedback Glove
A professional force-feedback teleoperation glove that combines 21-degree-of-freedom joint capture with real grasp resistance at the fingertips. Sixteen potentiometers and five servos deliver up to 3…
Look and see
- Briefly describe: A professional force-feedback teleoperation glove that combines 21-degree-of-freedom joint capture with real grasp resistance at the fingertips. Sixteen potentiometers and five servos deliver up to 3…
- Product Model: FFG Force Feedback Glove
A professional force-feedback teleoperation glove that combines 21-degree-of-freedom joint capture with real grasp resistance at the fingertips. Sixteen potentiometers and five servos deliver up to 3.5 kg·cm of feedback torque, and the wired 100 Hz or wireless 30 Hz link keeps command and response in millisecond sync. Both wired (interference-free, for demanding industrial use) and wireless operation are supported, for dexterous-hand teleoperation, VR interaction, medical simulation and industrial remote support.
Technical specifications
| Model | LFFG1-02 |
| Degrees of freedom | 21 (full-joint capture) |
| Sensors / actuators | 16 potentiometers + 5 servos |
| Capture accuracy | 0.08° |
| Maximum torque output | 3.5 kg·cm |
| Weight | 390 g |
| Data rate | wired 100 Hz / wireless 30 Hz |
| Transmission distance | ≤ 5 m indoors |
| Power | 5 V via USB Type-C |
| Dual-mode link | wired serial or wireless |
Documentation & compliance
- Datasheet (PDF) and 3D STEP model are provided for engineering evaluation.
- HS code and RoHS / REACH declarations are confirmed against the final configuration before shipment.
- Component-level compliance: this item is a robot component, not a finished machine — CE marking of the end system remains the integrator's responsibility.
Ordering & delivery
Prices are quoted in EUR, EXW. Lead time, freight and duties are confirmed per order. For volume pricing, samples or a formal quotation, send your BOM to sales@worldrobots.cn.
