Arm P7 — 7 DOF Lightweight Robot Arm
A 7-degree-of-freedom commercial arm for embodied AI and lightweight automation. Each joint integrates motor, driver and planetary reducer into one compact module for efficient power transfer, and th…
Prices are quoted net. VAT applies to shipments delivered duty paid (DDP) to the selected destination; on EXW / FOB / DAP terms the buyer accounts for import VAT locally. The rate shown is the standard rate and is confirmed on the final quotation.
Loading...
-
Optional specifications
Look and see
- Briefly describe: A 7-degree-of-freedom commercial arm for embodied AI and lightweight automation. Each joint integrates motor, driver and planetary reducer into one compact module for efficient power transfer, and th…
- Product Model: Arm P7
A 7-degree-of-freedom commercial arm for embodied AI and lightweight automation. Each joint integrates motor, driver and planetary reducer into one compact module for efficient power transfer, and the classic 7-DOF kinematics gives the redundancy needed for complex trajectories. At 5.6 kg it deploys quickly yet carries a 3 kg rated load (1:2 payload-to-weight) over a 608 mm working radius with ±0.043 mm repeatability, while 100 rpm joint speed keeps sort, pick and place cycles fast.
Technical specifications
| Degrees of freedom | 7 |
| Working radius | 608 mm |
| Rated load | 3 kg (payload-to-weight ratio 1:2) |
| Repeatability | ±0.043 mm |
| Weight | 5.6 kg |
| Working voltage | 48 V |
| Power | 11 W static / 258 W maximum |
| Maximum joint speed | 100 rpm |
| Control interface | CAN / CAN FD |
| Working temperature | 0–50 °C |
Documentation & compliance
- Datasheet (PDF) and 3D STEP model are provided for engineering evaluation.
- HS code and RoHS / REACH declarations are confirmed against the final configuration before shipment.
- Component-level compliance: this item is a robot component, not a finished machine — CE marking of the end system remains the integrator's responsibility.
Ordering & delivery
Prices are quoted in EUR, EXW. Lead time, freight and duties are confirmed per order. For volume pricing, samples or a formal quotation, send your BOM to sales@worldrobots.cn.
